Device description
The equipment is mainly used to convert the sound energy of the power superaudio source into mechanical vibration through the transducer, and the ultrasonic radiation is transmitted to the cleaning fluid in the tank by cleaning the wall of the tank. Because of the radiation of the ultrasound, the microbubbles in the liquid inside the tank can vibrate by the action of the sound waves. The adsorption of the surface of the dirt and the cleaning part causes the fatigue damage of the dirt layer to be refuged. The vibration of the gas body bubbles is scrubbed on the solid surface. It is suitable for many kinds of materials such as leaf vegetables, root vegetables, fish and shrimp, conch, etc.
Working principle
High frequency oscillation signal from the ultrasonic generator, transducer into high frequency mechanical oscillation and spread to the media, cleaning solvents, ultrasonic radiation forward in cleaning fluid density interaction, make the liquid flow and produces tens of thousands of a diameter of 50-500 microns of tiny air bubbles, exist in the tiny air bubbles in the liquid in the sound field under the action of vibration.
Technical parameters
| Product name |
ultrasonic cleaning machine |
| Model |
jpuw-500 |
| Raw material |
food grade SUS304 high quality stainless steel (or customized according to customer requirements) |
| Processing capacity |
0.5 tons per hour to 10 tons per hour |
| Dimension |
According to customer requirements |
| Function |
Application of the equipment to ultrasonic cleaning of fruits and vegetables (with ozone cleaning)
Application of leaf vegetables, root vegetables, fish and shrimp, conch, etc |
Equipment features
1. Using the powerful cavity effect of ultrasonic wave, the dirt and oil can be cleaned in a short time.
2. Simple operation with large timer. You can set the time between 1 and 500 hours.
3. Use small spare parts to clean special cases. Attached drain valve is convenient for reverse cleaning agent.
4. Equipped with automatic chronometer, convenient management of time and maintenance time.
5. Standard leakage circuit breaker: used to detect a leakage power supply, make relay action, power switch off.
