Device description

Prepare pot also named beater, mixing cylinder, cylinder with energy saving, corrosion resistance, strong production capacity, easy clean, the advantages of simple structure, is mainly used for dairy products and sugar and other elements and a variety of drugs again stir well after the merge, is indispensable to dairy products, beverage, pharmaceutical equipment. Use the material as SUS304 or 316 stainless steel.

Working principle

This equipment points higher cylinder block, cylinder head, impeller, inlet and discharge valves are made from imported 1 cr18ni9ti stainless acid-resistant steel, according to technical conditions, GB741-80 block in polishing, with stirring paddle, mixing effect. At the top of the cycloid pin gear planetary reducer, drive the impeller, and installation and cleaning, and there are two open cylinder head for cleaning, the bottom of the cylinder as the slope, facilitate emptying, the other two inlet, can be connected to the pipe, facilitate continuous into the ingredients, with discharging mouth below, can be fitted with a plug valve and stir well, rotating the plug valve handle 90 degrees can be feeding, feeding end is closed, achieve the goal of stir well.

Technical parameters

Product name mixing tank

Equipment model JPPP-001

Main material consumption grade stainless steel plate SUS304 (or customized according to customer requirements)

Processing capacity: 0.5 tons per hour to 10 tons/hour (or customized according to customer requirements)

Size specification 500 to 10000 (unit: L)

The application of equipment is applicable to the mixing and mixing of dairy, food, beverage and other materials

Applicable range dairy, food, beverage and other materials

Equipment features

1. Stainless steel tank with light weight and small wind load; A 10-cubic meter of stainless steel spherical storage tank weighs only over 360 kilograms and is only 1/38 of the weight of the cement pool;

2. The wind load is small, the appearance is beautiful view, can cooperate with the advertisement use, is the extremely good environmental protection product;

3. Use stainless steel can to save a lot of water. At present, there are nearly 30,000 roof and underground reservoirs in guangzhou. Each reservoir is calculated by 10 cubic meters, and the water is cleaned 3-4 times a year, which wastes more than one million cubic meters of tap water. And because of the development of real estate, waste continues to expand. If switch to new stainless steel spherical water storage tank, can effectively eliminate waste phenomenon.
