Device description

Heat preservation tank energy saving, sound attenuation, corrosion resistance, strong production capacity, convenient cleaning, widely used in the dairy industry, food, pharmaceutical, chemical, beverage and other industrial sectors, for heating, heat preservation, sterilization or storage must be water equipment, especially suitable for babbitt disinfection and heat water.

Working principle

When working, open the hot water inlet valve and start the heat pump. The hot water is discharged from the overflow mouth (recyclable), and the stirring motor is started, and the continuous mixing material can achieve the thermal insulation effect. Keep the temperature of the material in the cylinder from the jacket.

Cold water or hot water (watch thermometer) for the purpose of insulation.

Technical parameters

Type of JP - B

JP - 600 B

JP - 1000 B

JP - 1200 B

JP - 1500 B

2000

Class capacitance

let

device

Internal design pressure (MPa) atmospheric pressure

Design temperature (15 ~ 126 ℃)

Constant pressure of test pressure (MPa)

Main material: 1Cr18Ni9Ti

Volume (L) 600, 1200, 1500, 2000

clip

sleeve

Inner diameter (mm) 1000 1100 1200 1300 1500

Design pressure (MPa) 0.4

Design temperature (142 ℃)

Test pressure (Mpa) 0.6

Main material: 1Cr18Ni9Ti

Storage medium water, steam

Motor power (KW) 0.4 0.75, 1.752.2

Overall dimensions

1500 x 1150 x

1700 * 1280 * 1700

1800 * 1300 * 1800

2000 * 1550 * 2000

2200 * 1650 * 2200

2400

Weight (Kg) 550, 725, 800, 850, 1000
