Enzymatic hydrolysis tank

Device description

The enzymatic tank (also known as the enzymatic reaction tank, enzymatic hydrolysis reactor)  is widely used as indispensable vessel for for enzymic hydrolysis process for food, beverage, biological, pharmaceutical engineering and other industries. With enzyme as catalyst and agitator running under optimum temperature and pH value, the enzymatic reaction will take place in the tank

Working principle

Enzymatic hydrolysis of pharmaceutical, fine chemical and biological products of is a sterile and non pollution process, Our enzymatic tanks provide an aseptic system and avoid microorganism pollution so it greatly prolong your product’s shelf life and improve the quality.We specially designed and installed sterile breathing holes and positive pressure enzyme system. The heating and cooling can be carried out in circulation by heating or cooling medium.And we use polyurethane foam as insulation material.The material contact parts are all made of stainless steel, SUS304 or SUS316L. And the outer surface is frosted and matt treated, which conform to the GMP standard.

Technical parameters

Products Name Enzymatic hydrolysis tank
Model JPEHT-001
Main material SUS304(316L, or customized)
Capacity 500L-8000L (customized)
Usage Reaction vessel for enzymic hydrolysis process
Application food, beverage, biological, pharmaceutical engineering and other industries

Equipment features

1, the tank is equipped with insulation jacket(can heating, cooling and holding the heat).
2, the upper and bottom head (or cone) are spinning R angle processing.
3, the inner wall of the tank is under mirror polished , finish Ra≤0.4μm with no hygiene corner.The closed design ensures the material is always under sterile condition to complete mixing and fermentation. The equipment also has air respirator, cleaning ball, sanitary manhole, mirror, optic lamp etc.
