Device description
Hot air circulation oven is a kind of dry equipment, which has low noise, reliable operation, controllable temperature and easy operation. It is widely used in the drying of powder, granular and bulk materials such as pharmaceutical, traditional Chinese medicine, vegetables and food. It make use of a special big axial flow fan cycle to work independently, through the built-in electric heating tube, with high power thyristor controller, PID intelligent temperature controller display, relay and other advanced control device to achieve high precision temperature control, realize the appointment function, automatic constant temperature, automatic alarm, automatic platoon is wet and overtemperature ladder control temperature control, and other functions of optional, make more human, automation control.
Working principle
Hot air drying oven with air as the carrier, make heat with steam or electricity or hot blast stove, from outside the box into the air after switch heating temperature, the fan forced circulation layered advection material for heat exchange after baking tray and bake dish, and take away the material moisture (water), returned to the heat exchanger (steam heating, electric heating) heating heating up again. After so many times cycle, hot air moisture increasing, the ability to absorb material moisture content is reduced, the need to open the platoon is wet valve, excluding some high wet hot air, breathe in some low temperature cold wind, in order to achieve the purpose of continuous dry material.
Technical parameters
| Product name |
hot air circulation oven |
| Model |
JPAB-100 |
| Raw material |
food grade SUS304 high quality stainless steel (or customized according to customer requirements) |
| Processing capacity |
0.3 tons/hour to 1 ton/hour (or customized according to customer requirements) |
| Dimension |
3250**1200*700 to 22,500 *2000*1800 (mm) |
| Application |
used to dryand dehydrate fruits, vegetables, medicinal materials, etc |
Equipment features
1. The whole box adopts the whole closed structure, the circulating in the hot air box and energy saving and efficiency.
2. Adopt the built-in heat-resistant circulating fan, greatly reduce heat loss and strengthen heat transfer.
3. There are adjustable uniform wind plates in the box, which can be adjusted up and down to make the temperature evenly in the box.
4. The insulation layer is 80mm thick, and the material is white super fine glass wool, which meets the GMP standard and the heat loss is small.
5. The baking tray is the standard of the industry, and the baking tray is suitable for many industries and is highly interchangeable. Customers and materials can be chosen by themselves.
6. Automatic thermostat control, overtemperature alarm, working time timing, appointment, mechanization production, batch product quality and stability, farewell to traditional artificial watch shift and weather service.
